USB Rechargeable AA Ni-Zn Batteries with Built-in Charging Port | Consumer Electronics | Batteries
USB Rechargeable AA Ni-Zn Batteries with Built-in Charging Port
Hong Kong
Booth: 3E-B37 | Audio Visual Products
Product Specification
Advantages

Eco-friendly, Non-flammable, Non-explosive

Capacity

1800mWh

Battery Type

Revolutionary

Voltage

Born 1.6v

Application

Best for high-drain applications (eg power tools/Children's toys/Flash/Microphone/Measuring instruments)

Size

AA

Brand

Luzcell

USB

Built-in Port

Product Description

Comparison Between Ni-Zn and Ni-MH Batteries:



FeatureNi-ZnNi-MH
Voltage (Nominal)1.6 V1.2 V
Energy Density (Wh/kg)100-180 Wh/kg60-100 Wh/kg
Charge CyclesUp to 1200 cycles500-1000 cycles
Self-Discharge Rate (per month)High (up to 10%)Low (1-5%)
Charging EfficiencyHighModerate
Environmental ImpactNo toxic (no heavy metals like cadmium)Contains rare earth elements
Operating Temperature Range-20°C to 60°C-20°C to 50°C
CostModerateLower
Application SuitabilityBest for high-drain applications (e.g. power tools)Common in consumer electronics and hybrid vehicles;Not enough for modern smart devices.


Applications:

Best for high-drain applications (eg power tools/Children's toys/Flash/Microphone/Measuring instruments).





Advantages:

Nickel–zinc batteries perform well in high-drain applications, and may have the potential to replace lead–acid batteries because of their higher energy-to-mass ratio and higher power-to-mass ratio — as little as 25% of the mass for the same power.

The European Parliament has supported bans on cadmium-based batteries. Nickel–zinc is a good alternative for power tools and other applications.

NiZn is a good battery choice for applications requiring high-power and high-voltage.

Nickel–zinc cells have an open circuit voltage of 1.85 volts when fully charged and a nominal voltage of 1.65 V. This makes NiZn an excellent replacement for electronic products designed to use 1.5 V alkaline primary cells.

NiZn batteries do not use mercury, lead, or cadmium, or metal hydrides, all of which can be difficult to recycle. Both nickel and zinc are commonly occurring elements in nature, and can be fully recycled.

NiZn cells use no flammable active materials or organic electrolytes.

Properly designed NiZn cells can have very high power density and low-temperature discharging performance, and also can be discharged to almost 100%, and recharged without problems.

Zinc is a cheap and abundant metal, the 24th most abundant element in the Earth's crust, and is not dangerous to health. Common oxidation is +2, so charge and discharge move two electrons instead of one as in NiMH batteries.


Production Lead Time

35 days

Product Certifications
ROHS
Issued ByShenzhen TCT Testing Technology Co., LTDType
ROHS
Valid Date29 Nov 2022 - (N/A)
FCC
Issued ByShenzhen TCT Testing Technology Co., LTDType
FCC
Valid Date29 Nov 2022 - (N/A)
CE
Issued ByShenzhen TCT Testing Technology Co., LTDType
CE
Valid Date29 Nov 2022 - (N/A)
