7.0 Inch TFT LCD Modules 800*480 RGB TFT Display TFT LCD screen TTL Interface LCD Module
香港
展位编号: 5B-F09 | 显示技术世界
产品规格
尺寸
7.0inch
品牌
Microtech
型号编号
MTF070AT9309A-V2
是否可订造
可以
产品简介
Item | Specification |
Screen Size | 7.0 inch (Diagonal) |
Driver element | a-Si TFT active matrix |
Resolution | 800X480 |
Display mode | Normally |
Dot pitch | 0.0635(W)X0.1905(H) mm |
Active area | 152.4 (W)X91.44 (H) mm |
Module size | 165(W)X104.09(H)X5.3(D) mm |
Interface | Digital (TTL) |
Backlight power consumption | 1.5W (Typ.) |
Panel power consumption | 0.66 W(Typ.) |
生产所需时间
25-45 日
