产品规格
型号编号
MTF028QV62A-V1
尺寸
2.8inch
是否可订造
可以
品牌
Microtech
产品简介
Item | Main LCD | Unit | Note |
LCD Type | 2.8 TFT LCD | - | |
Display color | 16.7M | - | |
Driver Mode | Normally White | ||
Viewing Direction | ALL | O"clock | |
Active Area(W * H) | 43.20*57.60 | mm | |
Outline Dimensions | 50.00*69.20*2.30±0.15 | mm | |
Number of Dots | 240*(RGB) * 320 | Dots | |
Dot Pitch(W * H) | 0.180 (H)x 0.180 (V) | mm | |
Backlight | LED( white) | - | |
Controller | ST7789V | - | |
Operating Temperature | -20 +70 | - | |
Storage Temperature | -30 +80 | ||
LCM Luminous : | 350 | Cd/m2 | |
Data Transfer | Four-wire Serial Port | - |
Note 1: Select by software, and color tune is slightly changed by temperature and driving voltage.
Note 2:TBD- To Be Determined.
Note 3:Requirements on Environmental Protection: RoHS
生产所需时间
25-45 日
